Design: Narrow hydraulic removable non-ground bearing - swing radius of 102 inches (11 ft 11 in overall gooseneck length) - set up for wet line operation
Swing radius: 102 inches
Deck
Deck type: Flat level deck design
Deck length: 29 feet 0 inches clear deck length
Loaded deck height/clearance: 20 inches with 6 inches ground clearance
Flooring: 1 3/8 inch nominal wood (full width)
Axles
Standard trailer axles: 2
Axle Capacity: 25,000 lb. nominal capacity per axle NOTE: GAWR determined by suspension type, brakes, tires and other components.
Axle spread: 54.5 inches (between axles)
Bogie
Deck to bogie
connection: Fixed
Covered Rear Bogie: Rear bogie platform with 1 1/8 inch wood floor
Rear bogie height: 40 inches
Tires
Tire size: 255/70R 22.5 H ply OEM Standard
Weight
Estimated weight from 17,240 lbs.
Standard Features
Framework: All main longitudinal members fabricated with 100,000# minimum yield steel flanges with 50,000# webs
Loaded Fifth Wheel Height:
50 in nominal loaded fifth wheel height with 5 ride height positions
Electrical Receptacle: J560 7-pin connector
Crossmembers: On 12 inch centers
Front of deck sloped top down to assist in loading with traction cleats
Extension Brackets: Outriggers - 14 pair - 28 total removable swing type, 1 pair - 2 total removable hook-on type
Front Bogie Ramp: Sloped steel bogie ramp (full width)
Brakes: 16.5 inches x 7 inches with 5.5 inches autoslacks - heavy duty brake drums - outboard mount
Spring Brakes: Spring brakes (2 axles)
Suspension: Air ride with automatic controls
Wheels:
8.25 x 22.5 steel disc - hub-piloted
Bumper: 3 tail light package
Connections for Future Axle Attachment: Air and electrical connections to go along with connecting ears
Electrical System: DOT sealed beam and harness with LED lights and 4 inch flush mounted battery powered amber strobes
Lash Rings: 7 pair - 14 total
Flag Holders: 2 pair flag holders
ABS: 4S/2M system without diagnostic tool and cable
Liquid Filled Gauge: Included
Marker Lights: 7 marker lights per side including mid-turn
